srl-z series mixer is applicable for mixing, colouring and drying of various resin such as poly, pe,pp,pvc polypropylene, poly chloride etc.
features:
▲ all parts contacted with material is ss304 and material will not be contaminated.
▲ high cooling efficiency, short mixing time. easy and convenient to clean, and can reach high output.
▲ improved cooling efficiency and reduced water consumption.
▲ equipped with the pulse dust-cleaning recovery device.
▲ mixing tool coated with wear-resistant material, which can increase service life and past dynamic and static balance test,running smoothly.
▲ rapid,perfect after-sales service.
main technical parameters:
model | total volume （l） | effective volume (l) | blade speed(rpm) | motor power(kw) | dischargingway | batch （kg/batch） | mixing time(min) | |
srl-z 200/500 | 200/500 | 160/350 | 484/976-80 | 30/42/11 | manual / auto | 70 | 8-10 | 6-8 |
srl-z 300/600 | 300/600 | 240/420 | 475/950-70 | 40/55/11 | manual / auto | 100 | 8-12 | 6-10 |
srl-z 500/1000 | 500/1000 | 350/700 | 430/860-60 | 55/75/15 | manual / auto | 180 | 8-12 | 6-10 |
srl-z 800/1600 | 800/1600 | 640/1120 | 357/714/-50 | 83/110/22 | manual / auto | 280 | 8-12 | 6-10 |
